Time Delay Relay

Author	Views	Views Today	Rank	Comments
	197,054	114		65

A time delay relay is a relay that stays on for a certain amount of time once activated. This time delay relay is made up of a simple adjustable timer circuit which controls the actual relay. The time is adjustable from 0 to about 20 seconds with the parts specified. The current capacity of the circuit is only limited by what kind of relay you decide to use.

Schematic

Parts

Part	Total Qty.	Description	Substitutions
R1	1	1 Meg Pot
R2	1	10 K 1/4 Watt Resistor
C1	1	10uf 25V Electrolytic Capacitor
C2	1	0.01uf Ceramic Disc Capacitor
D1,D2	2	1N914 Diodes
U1	1	555 Timer IC
RELAY	1	9V Relay
S1	1	1A 120V SPST Switch
MISC	1	Board, Wire, Socket For U1

Notes

R1 adjusts the on time.

You can use a different capacitor for C1 to change the maximum on time.

S1 is used to activate the timing cycle. S1 can be replaced by a NPN transistor so that the circuit may be triggered by a computer, other circuit, etc.

Related Circuits

Comments

Add A Comment

Waqas Time Delay Relay Tuesday, August 25, 2009 4:52:29 AM

Hey this is a really nice and easy circuit to follow, but i was wondering if this can be applied to a 220v supply?? As i want a delay in my power when the relay detects another power source.

anonymous Time Delay Relay Monday, August 17, 2009 6:32:00 AM

hi, i built this circuit it works perfectly when there is no load at the relay, but when i put a load on a relay the circuit works abnormal...pls help me..

AB Time Delay Relay Monday, August 10, 2009 11:29:41 PM

I have the same problem as Mohsin - power up and relay turns on and the circuit closes. This occurs without the switch. As soon as power applied relay trips and stays on until power removed. Is there a common error that I might look for in my build?

Mae Time Delay Relay Sunday, August 09, 2009 10:55:30 AM

circuit is not working to me :( can anyone tell me where am i making mistake...all components new...

Mohsin Time Delay Relay Monday, June 08, 2009 11:54:05 PM

Hello I have build this circuit but the problem is that there is no delay. if its on it will remain ON and does not turn off. Please help Thx and Regards

WillyAG Time Delay Relay Saturday, June 06, 2009 5:58:27 PM

For timed relay action when the entire circuit is powered up, I put a capacitor (10uf) in place of the switch. On power up, the relay swirtches on for 10 seconds then off for as long as the circuit has power. Thanks for the info, the circuit you designed works perfectly. The fact that you would spend the time helping others is what's really good about the Internet.

Graham Time Delay Relay Saturday, May 02, 2009 1:28:56 AM

Hi All, How can i build a timer relay that will run for a prox 8min and then switch itself off. Then switch itself on once a button is pushed running the 8min timer again? This is a solar powered project that charges a batt and the batt will run a screen. Outdoors. Cheers in advance..

tim Time Delay Relay Monday, April 27, 2009 9:24:07 AM

hi sir, i'm an electronics student, my cousin and i are planning to make an automobile's horn with time delay, does this circuit work with it? thanks.

Nicolai Time Delay Relay Friday, April 17, 2009 2:55:36 PM

Hi I build up this circuit and done a PCB design of it too and works me perfectly. I want to know a brief description of each component what is doing. My timer operates between 0 to 50seconds beacuse I changed the value of R1 and C1. I wish to hear from you thankyou. Regards Nicolai

priyanka Time Delay Relay Thursday, April 02, 2009 6:00:17 AM

Dear Sir, Is there any variations occurs in turn time delay, when we extend weightiest slowly i.e. form 4000 to 16000 ? Means when we measure turn on time delay with the help of oscilloscope, Is waveform diagram same for all model or they differ in their AC-DC slpoes?
