| MeIsHere |
Ringing Phone Light Flasher |
Thursday, January 31, 2013 8:52:50 PM |
| Thank you for the circuit , I was tested this circuit , and it works good .
68 |
| TONY |
Ringing Phone Light Flasher |
Tuesday, November 13, 2012 4:45:46 PM |
| Can you substitute the +5V dc with +12V dc for the relay side of the circuit, as I cannot find solid-state relays that works with less than 12V dc. |
| AbiG |
Ringing Phone Light Flasher |
Sunday, July 29, 2012 6:13:27 AM |
| Thank you for defining this circuit; I was able to make it work...but I notice that the Relay chatters or turns On/Off while Ringing.
Normally, Telephone Ring is not continuous – it produces ringing tone once in 2 seconds…then the Relay also turns On/Off proportionately.
I believe adding a Capacitor to delay the turn OFF won’t work in this circuit as it works in Negative going pulse.
Is it possible to replace the circuit with PNP transistor? OR
Is there any standard way to turn the Relay ON continuous ?
|
| AbiG |
Ringing Phone Light Flasher |
Saturday, June 02, 2012 11:21:12 AM |
| Telephone Ringing. Telephone Ring is not continuous – it produces ringing tone once in 2 seconds…then the Relay also turns On/Off proportionately.
I believe adding a Capacitor to delay the turn OFF won’t work in this circuit as it works in Negative going pulse.
Is it possible to replace the circuit with PNP transistor? OR
Is there any standard way to turn the Relay ON continuous ?
|
| Phil |
Ringing Phone Light Flasher |
Sunday, May 06, 2012 12:45:14 PM |
| Well it does work butit works wrong the transistor is a npn so the relay is on until the phone rings., great if you are using a double pole relay not so great if your not . And yes the triac trik will work but why not use a solid state relay which has an inbuilt opti in it anyway so its just a cap one diode 1 resistor and the solid state relay |
| Michael |
Ringing Phone Light Flasher |
Wednesday, January 18, 2012 9:14:26 AM |
| Working on an offshore platform, I put this circuit in our emergency-phone, using 2 LED´s instead of D3 & U1 (Otherwise i used the spcified components), so the operators easily can identify when someone is calling on that line..Thanks :-) |
| John Stancliff |
Ringing Phone Light Flasher |
Monday, January 09, 2012 9:36:16 PM |
| Schematic show a external voltage of 5 Volts.... no reference given in notes concerning this..... why? (Editor's notes: It is assumed the reader will make up a 5V supply. Or just use 3 1.5V batteries in series.) |
| Laguna |
Ringing Phone Light Flasher |
Monday, December 19, 2011 8:20:41 PM |
| Sir, i have prepared every part of the circuit and constructed it diligently according to the schematic but nothing happened. Please help me solve about it. I may have missed some details of the circuit. |
| C N Dhavan |
Ringing Phone Light Flasher |
Saturday, November 22, 2008 3:50:46 AM |
| AS per the above electronic drawing, we have prepared the circuit with all specified components. But the circuit is not working. Please advise us next corrective action. |
| Diego E Pomeranec |
door bell chimer Light Flasher |
Friday, October 24, 2008 1:11:59 PM |
| I am deaf since i was born. I have moved to a new house where there are four bedrooms. I am getting difficult of getting a new door bell with flasher. I am living in argentina south America where there is not enough upgraded technology. I am wondering if you do have some knowledge about this technology and I am willing to purchase the items to develop my own door bell with RF flasher/chime.
What I need for my new home is :
-one wire door bell button for the front door (already have one installed)
- one main door bell chime with RF sender and a flasher (wireless) (for the kitchen where there is already a wire door bell phone)
-four wireless RF receiver with flasher and chime (one for each room)(I don’t know how far can RF receive the signal from the RF sender as maxium and remember that my house is too big like that 20 meters away X 20 meters away)
Door bell button --> main wire bell chime with RF sender / Flasher --> 1th wireless RF receiver / Flasher-chime / RF sender --> 2nd wireless RF receiver / Flasher-chime / RF sender --> 3th wireless RF receiver / Flasher-chime / RF sender --> 4th wireless RF receiver / Flasher-chime / RF sender
I hope you could get some time for make it up and thanks for your time
Regards
Diego E Pomeranec
|
