Telephone Recorder

Home > Circuits > Telephone > Telephone Recorder

Author	Views	Views Today	Rank	Comments
	222,465	14		55

This nifty little circuit lets you record your phone conversations automatically. The device connects to the phone line, your tape recorder's microphone input, and the recorder's remote control jack. It senses the voltage in the phone line and begins recording when the line drops to 5 volts or less.

Schematic

Parts

Part	Total Qty.	Description	Substitutions
R1	1	270K 1/4 W Resistor
R2	1	1.5K 1/4 W Resistor
R3	1	68K 1/4 W Resistor
R4	1	33K 1/4 W Resistor
C1	1	0.22uF 150 Volt Capacitor
Q1, Q2	2	2N4954 NPN Transistor
D1	1	1N645 Diode
MISC	1	Wire, Plugs To Match Jacks On Recorder, Board, Phone Plug

Notes

The circuit can be placed anywhere on the phone line, even inside a phone.

Some countries or states require you to notify anyone you are talking to that the conversation is being recorded. Most recoders do this with a beep-beep. Also, you may have to get permission from the phone company before you connect anything to their lines.
