50 Watt Amplifier

Author Views Views Today Rank Comments
96,402 11 62
This is a handy, easy to build general purpose 50 watt amp. The amp has an input for a radio, TV, stereo or other line level device. It also has a phono input for a record player, guitar, microphone or other un-amplified source. With the addition of a low pass filter at the input, it makes a great amp for a small subwoofer.

Schematic

This is the schematic of the 50 Watt Amp

Parts
Part
Total Qty.
Description
Substitutions
R11200 Ohm 1/4 W Resistor
R21200K 1/4 W Resistor
R3130K 1/4 W Resistor
R511K 1/4 W Resistor
R615K 1/4 W Resistor
R7,R1021 Meg (5%) 1/2 W Resistor
R8,R920.4 Ohm 5 W Resistor
R11110K Pot
R12,R13251K 1/4 W Resistor
R14147K 1/4 W Resistor
C11100uF 35V Electrolytic Capacitor
C210.011uF Capacitor
C313750pF Capacitor
C4,C621000pF Capacitor
C5,C7,C830.001uF Capacitor
C9150pF Capacitor
C1010.3uF Capacitor
C11,C12210,000uF 50V Electrolytic Capacitor
U1,U22741 Op Amp
U31ICL8063 Audio Amp Transister Driver thingy
Q112N3055 NPN Power Transistor
Q212N3791 PNP Power Transistor
BR11250 V 6 Amp Bridge Rectifier
T1150V Center Tapped 5 Amp Transformer
S11SPST 3 Amp Switch
S21DPDT Switch
F112 Amp Fuse
SPKR118 Ohm 50W Speaker
MISC1Case, Knobs, Line Cord, Binding Posts Or Phono Plugs (For Input And Output), Heatsinks For Q1 And Q2

Notes

  1. I know I skipped R4. That is not a problem :-)

  2. Distortion is less than 0.1% up to 100HZ and increases to about 1% at 20kHz.

  3. I haven't been able to find anyone who sells a suitable T1. You can always use two 24V 5A units in series. If you are building two amps (for stereo), then I would suggest using an old microwave transformer and rewinding it. Follow the instructions in the 12V To 120V Inverter, execpt wind 26 turns, twist a loop (center tap) and wind 26 more turns. That should work out to around 50 volts. You may need to add or remove turns depending on your transformer.

  4. Q1 and Q2 will require heatsinks.

  5. You may have trouble finding U3 because it is discontinued. Please don't email me about sources...I can't find it either. See if any of the sources in Where To Get Parts has it. A possible source was sent in by JBWilliams:
    Zigma Electronics
8803 Shirless Ave.
Northbridge, CA 91324
United States
Phone: 818-772-7590
